Premium Solar Accessories
Engineering PV Junction Boxes and Connectors for Utility-Scale Solar
1500V DC
Rated voltage
30A
Rated current
-40C to +85C
Ambient temp
UF-JX-90 / 1500V DC
TUV
Certified
B 132787 0001
Certificate No
UL94-V0
Flame Class
IP68
1m, 1h
PRODUCTS
UF-JX-90
PV Split Junction Box
- Split design construction
- Horizontal outlet configuration
- Simplified internal circuit design
UF-CN-15
Solar Connector
- Rear-insert assembly method
- Superior resin insulation material
- Pressure welding connection
Solutions by Solar Application
The split designensures:
- Reduced cable bending
- Lower mechanical stress
- Better hot-spot distribution
Available variants:
- 20A
- 25A
- 30A
Junction boxes for module production.
High-voltage DC arrays and outdoor use.
Sealed connector systems for current flow.
Built Around Certified Materials and Outdoor Protection
55A
Reverse Current
0.3
Max mOhm Contact Resistance
TUV certified PV junction box design
UL94-V0 flame class material build
IP68 weatherproof for outdoor usage
Potting and seal-ring waterproofed
Built for Utility-Scale Solar Conditions
Rated Current
30A
Rated Voltage
1500V DC
Protection
IP68
Ambient Temp
-40/+85C
| Parameter | Measurement Value |
|---|---|
| Certifications | TUV |
| Certificate No | B 132787 0001 |
| Rated Voltage | 1500VDC |
| Max Working Voltage | 1500V DC |
| Rated Current | 20A, 25A & 30A |
| Reverse Current | 55A |
| Ambient Temp | -40C to +85C |
| Protection Degree | IP68 (1m, 1h) |
Certifications
TUV
Certificate No
B 132787 0001
Rated Voltage
1500VDC
Max Working Voltage
1500V DC
Rated Current
20A, 25A & 30A
Reverse Current
55A
Ambient Temp
-40C to +85C
Protection Degree
IP68 (1m, 1h)
Hover to zoom
Consult with us on Product Selection
PV junction boxes, connectors, and project-ready component support.
